Concrete Pre-Pour Inspection Checklist

Concrete Pre-Pour Inspection Checklist

1. Project Details

• Project Name
• Location
• Inspection Date
• Inspector Name
• Weather Conditions
• Temperature

2. Formwork

• Formwork Stability
• Securely brace and stable the formwork .
  • Are all connections tight and secure?
• Formwork Dimensions
  • Are the formwork dimensions correct as per drawings?
  • Check the formwork for squareness and levelness.
• Formwork Cleanliness
  • Is the formwork free from debris and contamination?
  • Treat the formwork with a release agent.

3. Reinforcement

• Rebar Installation
  • Are rebar sizes and spacing according to the design specifications?
  • Is the reinforcement free from rust, oil, or other contaminants?
• Rebar Ties and Supports
  • Are all rebar ties secure?
  • Are all rebar supports in place and adequately spaced?
• Clearances
  • Are the required clearances between rebar and formwork maintained?
  • Are corner bars and lap splices properly installed?

4. Embedded Items

• Placement of Embedded Items
  • Properly position and secure all embedded items (e.g., anchor bolts, sleeves, conduits).
  • Are embedded items clean and free from contaminants?
• Alignment and Elevation
  • Align all embedded items and keep at the correct elevation.

5. Subgrade and Base Preparation

• Subgrade Condition
  • Properly compact the subgrade.
  • Is the subgrade free from standing water, mud, or debris?
• Base Material
  • Compact and keep the base material in place as per specifications.
  • Is the thickness of the base material adequate?

6. Joints and Joint Materials

• Expansion and Control Joints
  • Are expansion and control joints in the correct locations and as per design?
  • Are joint fillers and sealants in place and properly installed?
• Isolation Joints
  • Install isolation joints where required (e.g., around columns)?

7. Utilities and Drainage

• Utility Conduits and Piping
  • Are all utility conduits and piping properly placed and protected?
  • Is there adequate coverage of concrete over conduits and piping?
• Drainage
  • Properly grade the site for drainage?
  • Are drainage systems installed and operational?

8. Access and Safety

• Site Access
  • Is there clear and safe access for concrete delivery?
  • Remove any obstruction.
• Safety Measures
  • Are all necessary safety barriers and signs in place?
  • Equip workers with proper PPE.

9. Quality Control and Documentation

• Mix Design Verification
  • Has the concrete mix design been approved?
  • Is there a copy of the mix design on site?
• Batching and Delivery
  • Are concrete delivery tickets being checked?
  • Is the concrete slump tested before pouring?
• Inspection Reports
  • Are all previous inspection reports available and reviewed?
  • Is there a record of any corrective actions taken?

10. Final Sign-Off

• Inspection Approval
  • Has the pre-pour inspection been completed and approved?
  • Are all identified issues resolved?
• Signatures
  • Inspector’s Signature
  • Contractor’s Signature
  • Engineer’s Signature (if required)

Using eAuditor Audits & Inspection for this Checklist

1. Create a Template: Open eAuditor Audits & Inspection and create a new template. Use the above checklist structure to add relevant sections, questions, and response options.
2. Assign Actions: You can assign corrective actions directly within the checklist for any issues identified.
3. Add Photos and Notes: eAuditor Audits & Inspection allows you to attach photos and notes to each item, which is useful for documenting specific conditions.
4. Set Up Notifications: Set up notifications to alert relevant team members when an inspection is completed or if any issues are noted.
5. Generate Reports: After completing the inspection, you can generate a report directly from eAuditor Audits & Inspection to share with the project team.

This checklist will ensure that all critical aspects of the pre-pour inspection are covered, helping to prevent issues during the concrete pour.
