Roof Sheathing & Shear Wall Inspection Checklist
Here’s a Roof Sheathing & Shear Wall Inspection Checklist that can be implemented in eAuditor Audits & Inspections. This checklist is designed to ensure that roof sheathing and shear wall installations comply with safety and building code requirements, and identify areas that may require corrections.
Roof Sheathing & Shear Wall Inspection Checklist Template
1. Inspection Details
- Inspection Title: Roof Sheathing & Shear Wall Inspection
- Date of Inspection: [Date]
- Location: [Location/Project Address]
- Inspector’s Name: [Inspector]
- Contractor Name: [Contractor]
- Weather Conditions: [Sunny, Cloudy, Rainy, Windy, etc.]
2. General Information
- Project Stage: (e.g., Pre-installation, Mid-installation, Final Inspection)
- Permit Available: Is the building permit visible on site? (Yes/No/Comments)
- Plans On-Site: Are the roof and shear wall plans available on site? (Yes/No)
- Safety Gear Worn: Are all workers wearing appropriate personal protective equipment (PPE)? (Yes/No/Comments)
3. Roof Sheathing Inspection
Section 1: Materials & Installation
- Sheathing Type: Use of correct sheathing material (plywood, OSB, etc.) as per plan? (Yes/No/Comments)
- Sheathing Thickness: Does the sheathing thickness meet the specified requirements? (Yes/No/Thickness Measured)
- Proper Nailing Pattern: Is the nailing pattern per plan or manufacturer’s specifications? (Yes/No/Nail Spacing)
- Nail Size & Type: Use of the correct nail sizes and types being used. (Yes/No/Comments)
- Edge Nailing: Proper installation of nails along the edges of the roof sheathing? (Yes/No)
- Panel Staggering: Is the roof sheathing properly staggered, with no continuous joints? (Yes/No/Comments)
- Gaps Between Panels: Are there proper gaps between panels for expansion (1/8 inch)? (Yes/No/Comments)
- Sheathing Damage: Is there any visible damage or defects in the sheathing? (Yes/No/Comments)
- Overhang Support: Are roof sheathing overhangs adequately supported? (Yes/No)
Section 2: Fasteners & Connections
- Fastener Spacing: Is the fastener spacing consistent and as per plan? (Yes/No/Spacing Measured)
- Missed Nails: Are there any nails that missed the framing members? (Yes/No/Comments)
- Panel-to-Rafter/Truss Connection: Proper connection of panels to the rafters or trusses. (Yes/No/Comments)
Section 3: Roof Ventilation
- Ventilation Holes Cut: Proper cutting of ventilation holes for attic ventilation? (Yes/No/Location of Holes)
- Eave and Ridge Venting: Is eave and ridge venting installed correctly? (Yes/No/Comments)
4. Shear Wall Inspection
Section 1: Material & Framing
- Sheathing Type for Walls: Use of the correct shear wall sheathing material. (Yes/No/Material Type)
- Sheathing Thickness for Walls: Is the thickness of the sheathing correct as per plans? (Yes/No/Comments)
- Stud Spacing: Correct spacing of wall studs as per the plans (e.g., 16″ or 24″ on center)? (Yes/No/Comments)
- Panel Alignment: Are shear wall panels aligned with framing and properly spaced? (Yes/No)
- Blocking Installed: Are blocks installed where needed for vertical and horizontal shear transfer? (Yes/No/Comments)
Section 2: Fastening and Connections
- Nailing Pattern: Is the nailing pattern correct for the shear wall? (Yes/No/Nail Spacing)
- Nail Size and Type for Shear Walls: Are nails of the correct size and type used as per engineering specs? (Yes/No)
- Nailing at Panel Edges: Are nails at panel edges placed correctly and spaced as per plan? (Yes/No)
- Hold-Downs Installed: Are hold-downs installed where required, and are they the correct type? (Yes/No/Comments)
- Anchor Bolts: Are anchor bolts installed correctly and at the proper spacing? (Yes/No/Spacing Measured)
- Straps and Tie-Downs: Are tie-downs and straps installed and fastened securely? (Yes/No/Location of Straps)
Section 3: Openings and Detailing
- Sheathing Around Openings: Is the sheathing properly installed around window and door openings? (Yes/No/Comments)
- Header Connection: Are headers properly installed and connected at openings? (Yes/No/Comments)
- Edge Fastening at Openings: Are edges around openings fastened properly? (Yes/No/Comments)
Section 4: Shear Transfer
- Load Path Continuous: Is there a continuous load path from roof to foundation? (Yes/No/Comments)
- Floor-to-Wall Connection: Proper connecting of shear walls to the floor framing. (Yes/No)
- Wall-to-Roof Connection: Connecting of shear walls to the roof framing securely. (Yes/No)
5. Compliance and Safety
- Code Compliance: Does the installation comply with local building codes and engineering plans? (Yes/No/Comments)
- Safety Hazards Identified: Noting of any potential safety hazards during the inspection. (Yes/No/Details)
- Required Corrections: Identification of any corrective actions during the inspection? (Yes/No/Details)
6. Photos and Attachments
- Photo Evidence: Attach photos of any issues, defects, or areas requiring correction.
- Documents Attached: Attach any relevant documentation (e.g., engineering drawings, permits).
7. Inspector Comments and Sign-off
- Inspector’s Notes: Additional comments or observations.
- Inspector’s Signature: [Digital or Handwritten Signature]
- Date of Completion: [Date]
Customization Tips for eAuditor Audits & Inspections:
- Conditional Logic: Use eAuditor Audits & Inspection’s conditional logic to hide sections until certain conditions are met. For example, only show the “Corrections” section if a problem is detected.
- Photo Capture: Allow for photo attachments within the app to document issues and provide a visual record of both problem areas and corrective actions.
- Sign-off and Approvals: Use digital sign-off features for the inspector and any necessary approval from supervisors or engineers.
- Action Items: Create follow-up actions directly in eAuditor Audits & Inspections with deadlines and assigned responsibilities for corrections identified during the inspection.
